Product Specifications:
| Brand | NQCOMM |
| Gender | Plug |
| Orientation | Straight |
| Termination Style | Cable-Clamp |
| Impedance (Ohms) | 50 |
| Cable Type | Belden 9907, Belden B7806A, RG-141, RG-303, RG-58, RG-58A, RG-58B, RG-58C, Times Microwave LMR-195 |
| Body Finish | Nickel Plating |
| Body Material | Brass |
| Contact Finish | Gold Plating |
| Contact Material | Brass |
| Contact Termination | Solder |
| Insulator Material | PTFE |
| Coupling Mechanism | Bayonet |
| Max Frequency (GHz) | 4 |
| Polarity | Standard |
| Min Temp. (Celsius) | -65℃ |
| Max Temp. (Celsius) | 165℃ |
| Mating Cycles | 500 |
