Product Specifications:
| Brand | NQCOMM |
| Gender | Jack |
| Orientation | Straight |
| Termination Style | Solder Cup |
| Impedance (Ohms) | 50 |
| Cable Type | N/A |
| Body Finish | Nickel Plating |
| Body Material | Brass |
| Contact Finish | Gold Plating |
| Contact Material | Beryllium Copper |
| Contact Termination | Crimp |
| Insulator Material | PTFE |
| Coupling Mechanism | Solder |
| Mounting Feature | 4-Hole Flange |
| Max Frequency (GHz) | 11 |
| IP Rating | IP68 |
| Isolated | No |
| Low PIM | No |
| Non-Magnetic | No |
| Min Temp. (Celsius) | -65℃ |
| Max Temp. (Celsius) | 165℃ |
| Thread Direction | Standard |
